Aircraft Instruments and Equipment for CPL: What You Must Understand
For the DGCA CPL, aircraft instruments mean the pitot-static instruments (airspeed indicator, altimeter, vertical speed indicator), the gyroscopic instruments (attitude indicator, heading indicator, turn coordinator), the magnetic compass, and the electronic displays and safety equipment of modern aircraft. The exam tests how each works, what errors it has and what you see when something fails.
Memorising names is not enough. Questions ask about causes and effects, such as what happens to the altimeter if the static port blocks. This guide builds that understanding in the order a student meets it.
Updated October 2026 · Editorial team, Golden Epaulettes Aviation
Key facts: CPL aircraft instruments
- Pitot-static group: airspeed indicator, altimeter and vertical speed indicator, all driven by air pressure.
- Gyroscopic group: attitude indicator, heading indicator and turn coordinator, based on rigidity and precession.
- Magnetic compass: direct reading, with dip, acceleration and turning errors that you must be able to apply.
- Modern aircraft: electronic displays (PFD and ND), air data and inertial reference systems, and GPS.
- Where it is examined: instruments feature in the DGCA Air Navigation and Technical General papers; confirm the current syllabus on the DGCA site.
- Best study method: draw the system, then predict each failure.
The "six pack" and how each instrument works
The six basic flight instruments are the classic starting point. Three get their information from outside air pressure and three from spinning gyroscopes or equivalent sensors.
| Instrument | Source | Core CPL concept |
|---|---|---|
| Airspeed indicator | Pitot (total) and static pressure | Measures dynamic pressure; IAS, CAS, TAS and errors such as position and instrument error |
| Altimeter | Static pressure | Pressure-to-height conversion; QNH, QFE, standard 1013.25 hPa; pressure and temperature errors |
| Vertical speed indicator | Static pressure, with a calibrated leak | Shows rate of change of pressure; has a lag, instantaneous VSI uses accelerometers |
| Attitude indicator | Gyro with vertical axis | Rigidity in space, erection system, banking and pitch errors after turns and acceleration |
| Heading indicator | Gyro with horizontal axis | Needs resetting to the compass; drift from earth rotation and transport wander |
| Turn coordinator | Gyro with limited gimbal | Shows rate of roll and turn; ball shows balance, slip or skid |
Pitot-static system failures
A favourite exam theme is blockage. Learn it as a table and you can answer almost any variant. Remember that the airspeed indicator uses both pressures, the altimeter and VSI use only the static source.
| Blockage | Airspeed indicator | Altimeter | VSI |
|---|---|---|---|
| Pitot tube blocked, drain hole open | Reads zero or decays | Normal | Normal |
| Pitot tube and drain both blocked | Behaves like an altimeter: rises in climb, falls in descent | Normal | Normal |
| Static port blocked | Under-reads in a climb or over-reads in a descent | Freezes at the blocked height | Reads zero |
Know the backup too: an alternate static source, and pitot heating to prevent icing. A real-world reminder of why this matters is available in SKYbrary's pitot-static article.
Gyroscopic principles and errors
Two properties of a spinning gyro run the whole topic. Rigidity means the spin axis stays fixed in space, and precession means a force applied to the rim acts 90 degrees later in the direction of rotation.
- Apparent drift: a free gyro appears to drift because the earth rotates, at 15 degrees per hour times the sine of latitude.
- Transport wander: moving over the earth's surface causes extra apparent movement.
- Real drift: bearing friction and imperfect balance cause actual movement of the axis.
- Turn coordinator: because its gimbal is tilted, it senses both roll and yaw rate.
Ring laser and fibre-optic gyros in modern inertial systems follow different physics, but the exam still asks you to compare them with mechanical gyros.
The magnetic compass
The compass is the simplest instrument and the one with the most calculations attached. Expect questions on variation, deviation, dip and the errors during turning and acceleration.
- Variation: difference between true north and magnetic north, changes with place and year.
- Deviation: error caused by aircraft magnetic fields, listed on a compass correction card.
- Dip: the magnetic field leans into the earth, so the compass card tilts and errors grow near the poles.
- Acceleration error: on easterly or westerly headings, acceleration shows a turn towards north and deceleration towards south.
- Turning error: the compass under-reads or over-reads depending on hemisphere and the heading from which you turn.
Electronic displays and air data systems
Airliners and many modern trainers replace round dials with a Primary Flight Display (PFD) and Navigation Display (ND). The same six-pack information appears on the PFD, but it comes from air data and inertial reference units rather than individual instruments.
- PFD: attitude, speed, altitude, vertical speed, heading and flight mode annunciations.
- ND: route, waypoints, weather radar overlay and traffic.
- ADIRS or ADC and IRS: compute air data and attitude and feed all displays.
- GPS and FMS: provide position and the planned flight path.
The aircraft systems overview and SKYbrary's PFD article are useful companions.
Key safety and warning equipment
The CPL syllabus also asks about equipment that warns or protects the crew. Learn what each does and what it does not do.
| Equipment | Purpose |
|---|---|
| TCAS or ACAS | Warns of nearby traffic and issues resolution advisories |
| GPWS and EGPWS | Warns of terrain and unsafe closure with the ground |
| Weather radar | Shows precipitation and turbulence ahead |
| Flight data and cockpit voice recorders | Record parameters and audio for accident investigation |
| ELT | Transmits a distress signal after an impact |
| Oxygen and fire protection | Support crew and passengers in decompression or fire |
For traffic warning detail see SKYbrary on ACAS.
How to study instruments for the DGCA exam
- Draw each system from memory, labelling sources of pressure or power.
- Predict the effect of every failure and check against the textbook.
- Practise numerical items: drift rate, compass headings, altimeter setting corrections.
- Attempt timed question-bank papers and note repeated question types.
- Revise glass-cockpit terms last, since questions are more descriptive.
What this means for your pilot career
Instrument knowledge pays back at your first instrument rating and again during airline simulator checks, where failures are inserted without warning. Build the theory in CPL technical general and CPL air navigation, and use our CPL ground training guide to plan the full subject list.
Our DGCA CPL ground classes cover these papers in classroom and live online formats.
Sources and official references
- SKYbrary: Pitot-static system (accessed October 2026)
- SKYbrary: Primary Flight Display (accessed October 2026)
- SKYbrary: Airborne Collision Avoidance System (accessed October 2026)
- FAA Pilot's Handbook of Aeronautical Knowledge – faa.gov (accessed October 2026)
- DGCA India – dgca.gov.in (accessed October 2026)
